It's right for you if...

You want a comfy and fast ride that's built for the long haul, and prefer the feel of vibration-damping IsoSpeed and lightweight carbon. Rides might take you over smooth pavement, rough roads, and well beyond. You want a bike with wide tire clearance to get you through it all.

The tech you get

A light and refined 500 Series OCLV Carbon frame and fork with road-smoothing rear IsoSpeed, powerful flat-mount disc brakes, a full 2x12 Shimano 105 groupset, and tubeless ready wheels with wider 700x32 tires. An integrated cockpit, internal storage, top tube mounts, and cable routing add to the bike's capability and sleek look.

The final word

Carbon, comfort, capability. Domane SL 5 is the dream bike for long rides. Its light and fast carbon frame, stable endurance geometry, and road-smoothing rear IsoSpeed keep you comfortable through long miles. You also get the added advantage of a higher-end Shimano 105 drivetrain and powerful disc brakes that let you run wide tires.

Why you'll love it

1. Domane SL Gen 4's aero Kammtail tube shapes and rear IsoSpeed comfort technology come together for a super fast, light, and smooth ride
2. This bike is super versatile and equally suited to all-day adventures on the open road, club rides, and racing
3. The Shimano 105 groupset is reliable and won't break the bank
4. Road-smoothing IsoSpeed and clearance for up to 38mm tires absorbs fatiguing bumps in the road for a smoother, more comfortable ride
5. A convenient internal storage compartment gives you a versatile spot to stow tools and gear, while top tube mounts let you cleanly bolt on a bag for all day adventures

SPECIFICATIONS

*Please note - spec applies to all sizes unless listed separately

Frameset
Frame    500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle
Fork    Domane SL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle

Weight
Weight    56 - 9.02 kg / 19.89 lbs (with TLR sealant, no tubes)
Weight limit    This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

Drivetrain
Shifter    Shimano 105 R7120, 12 speed
Front derailleur    Shimano 105 R7100, braze-on, down swing
Rear derailleur    Shimano 105 R7100, 36T max cog
*Crank    Size: 44, 47
Shimano 105 R7100, 50/34, 165mm length
Size: 50, 52
Shimano 105 R7100, 50/34, 170mm length
Size: 54, 56
Shimano 105 R7100, 50/34, 172.5mm length
Size: 58, 60, 62
Shimano 105 R7100, 50/34, 175mm length
Bottom bracket    Praxis, T47 threaded, internal bearing
Cassette    Shimano 105 7101, 11-34, 12 speed
Chain    Shimano SLX M7100, 12 speed
Max chainring size    1x: 48T, 2x: 52/36

Wheels
Hub front    Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle
Skewer front    Bontrager Switch thru axle, removable lever
Hub rear    Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Skewer rear    Bontrager Switch thru axle, removable lever
Rim    Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve
Tire    Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm
Tire part    Bontrager TLR sealant, 180 ml/6 oz
Rim strip    Bontrager TLR
Max tire size    38mm without fenders, 35mm with fenders

Components
*Saddle    Size: 44, 47, 50, 52
Verse Short Comp, steel rails, 155mm width
Size: 54, 56, 58, 60, 62
Verse Short Comp, steel rails, 145mm width
*Seatpost    Size: 44, 47, 50, 52, 54, 56
KVF aero carbon seatpost, 20mm offset, 280mm length
Size: 58, 60, 62
KVF aero carbon seatpost, 20mm offset, 320mm length
*Handlebar    Size: 44, 47
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 36cm width
Size: 50
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm width
Size: 52
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width
Size: 54, 56
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 42cm width
Size: 58, 60, 62
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 44cm width
Handlebar tape    Bontrager Supertack Perf tape
*Stem    Size: 44
Trek RCS Pro, -7 degree, 60mm length
Size: 47
Trek RCS Pro, -7 degree, 70mm length
Size: 50
Trek RCS Pro, -7 degree, 80mm length
Size: 52, 54
Trek RCS Pro, -7 degree, 90mm length
Size: 56, 58
Trek RCS Pro, -7 degree, 100mm length
Size: 60, 62
Trek RCS Pro, -7 degree, 110mm length
Brake    Shimano 105 hydraulic disc, flat mount
Brake rotor    Shimano RT70, centerlock, 160mm
Rotor size    Max brake rotor sizes: 160mm front & rear

Accessories
Bag    Bontrager BITS Internal Frame Storage Bag

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
