It's right for you if...

You want a single bike you can use for fitness rides, commutes, and cruises, and you value the confidence that comes from the superior all-weather stopping power of disc brakes.

The tech you get

A lightweight aluminum frame with stepthrough geometry that's easier to mount and dismount, hydraulic disc brakes for all-weather stopping power, a Shimano drivetrain with 9 speeds and a wide range of gearing so you're never pedaling too hard or too soft, and mounts that make it easy to accessorize your ride!

The final word

FX 2 Stagger is a stylish, versatile hybrid bike that performs on fitness rides, trips to the market, or your morning commute. It has endless options for accessories, but what really sets this model apart is the disc brakes, which provide great stopping power in all weather conditions.

Why you'll love it

1. The stepthrough frame makes it easy to hop on and go, and hop off when your ride is over
2. The cables are routed internally, which protects them from the elements and adds to the bike's sleek look
3. It's easy to accessorize with racks, a kickstand, fenders, lights, and more!
4. Like every Trek hybrid, it's backed by a lifetime warranty and supported by a wide network of retail partners

SPECIFICATIONS

*Please note - spec applies to all sizes unless listed separately

Frameset
Frame    Alpha Gold Aluminum, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR
Fork    FX alloy, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR

Wheels
Hub front    Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Skewer front    139x5mm bolt-on
Hub rear    Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Skewer rear    152x5mm QR
Rim    Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve
Tire    Bontrager H2 Comp, wire bead, 30 tpi, 700x35mm
Max tire size    700x40mm

Drivetrain
Shifter    Shimano U4000, 9 speed
Rear derailleur    Shimano CUES U4000
Crank    ProWheel Pro alloy, 40T narrow-wide steel ring, 170mm length
Bottom bracket    Sealed cartridge, 68mm
Cassette    Shimano LINKGLIDE LG300, 11-46, 9 speed
Chain    Shimano LG500
Pedal    Bontrager City pedals
Max chainring size    1x: 44T, 2x: 46/32

Components
Saddle    Bontrager Sport Women's
Seatpost    Bontrager alloy, 27.2mm, 12mm offset, 330mm length
*Handlebar    Size: S, M
Bontrager alloy, 31.8mm, 15mm rise, 600mm width
Size: L
Bontrager alloy, 31.8mm, 15mm rise, 660mm width
Grips    Bontrager Satellite
*Stem    Size: S
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 90mm length
Size: M, L
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 100mm length
Brake rotor    Tektro wave, 6-bolt, 160mm
Brake Set    Tektro HD-R280 hydraulic disc, 160mm rotor
Rotor size    Max brake rotor sizes: 160mm front & rear

Weight
Weight    M - 11.90 kg / 26.24 lbs
Weight limit    This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
