It's right for you if...

A boost of power is just what you're after, but you don't drain the bank account. You want plenty of gears for riding all kinds of trails, and the flat protection offered by wide 2.6in tubeless-ready wheels and tires.

The tech you get

An Alpha Platinum Aluminum frame with real mountain bike geometry and an air-sprung 120mm fork. A reliable Bosch Active Line Plus 50Nm drive system capable of assisting you to speeds of 20mph/25kph. A compact Purion 200 remote with built in display and 400Wh Powertube battery. You get 12-speed Shimano Deore shifting, hydraulic disc brakes, and wide, 2.6in tubeless ready wheels that boost grip and help prevent flats.

The final word

Marlin+ is the go-to for riders looking to dip their toes into the electric mountain bike world. Its trail-savvy frame gives you confident control, and Bosch Active Line Plus motor offers enough power to take the burn out of long climbs.

Why you'll love it

1. Its AUTO mode adaptive motor support recognizes speed reductions and adjusts assistance automatically
2. The 120mm suspension keeps your ride feeling smooth through bumps, roots, and rough stuff
3. Marlin+ is easy to use with simple controls and intuitive support, so you can focus on the ride ahead, not complicated remotes
4. Trail-savvy geometry keeps handling easy and confident from singletrack to city streets
5. Tons of rack and fender mounts let you customize your ride for the trail or taking on daily commutes

SPECIFICATIONS

*Please note - spec applies to all sizes unless listed separately


Frameset
*Frame Size: XS
Alpha Platinum Aluminum, curved top tube, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle
Size: S , M , L , XL
Alpha Platinum Aluminum, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle
*Fork Size: XS
RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 46mm offset, Boost110, Maxle Stealth, 100mm travel
Size: S
RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 46mm offset, Boost110, Maxle Stealth, 120mm travel
Size: M , L , XL
RockShox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, Maxle Stealth, 120mm travel

Wheels
Hub front Shimano TC500 alloy, centerlock, 110x15mm thru axle
Hub rear Shimano TC500 alloy, centerlock, 148x12mm thru axle
Skewer rear Bontrager Switch thru axle, removable lever
*Rim Size: XS , S , M , L , XL
Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve
Size: XS , S , M , L , XL
Bontrager Line TLR 30, Tubeless Ready, 32-hole, Presta valve
*Tire Size: XS , S
Bontrager Gunnison Pro XR, Tubeless Ready, Inner Strength sidewalls, aramid bead, 60 tpi, 27.5x2.60"
Size: M , L , XL
Bontrager Gunnison Pro XR, Tubeless Ready, Inner Strength sidewalls, aramid bead, 60 tpi, 29x2.60"
Tire part Bontrager TLR sealant, 180 ml/6 oz
Rim strip Bontrager TLR

E-system
Battery Bosch CompactTube 400Wh
Charger Bosch standard 2A, 110V, smart system
Computer Bosch Purion 200
Motor Bosch Active Line Plus, 50 Nm

Drivetrain
Shifter Shimano Deore M6100, 12 speed
Rear derailleur Shimano Deore M6100, long cage
Crank FSA CK-220, 165mm length
Chain ring FSA, 32T, steel
Cassette Shimano Deore M6100, 10-51, 12 speed
Chain Shimano Deore M6100, 12 speed
Pedal VP-536 nylon platform

Components
*Saddle Size: XS , S , M , L , XL
Bontrager Verse P3, chromoly rails
Size: XS , S , M , L , XL
Bontrager Arvada, hollow chromoly rails, 138 mm width
*Seatpost Size: XS , S
TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length
Size: M , L , XL
TranzX JD-YSP18, 150mm travel, internal routing, 31.6mm, 470mm length
*Handlebar Size: XS , S
Bontrager alloy, 31.8mm, 15mm rise, 720mm width
Size: M , L , XL
Bontrager alloy, 31.8mm, 15mm rise, 750mm width
Grips Bontrager XR Trail Comp, nylon lock-on
*Stem Size: XS , S
Bontrager Comp, 31.8mm, 7 degree, 35mm length
Size: M , L
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: XL
Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length
Headset Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8" top, 1.5" bottom
Brake Shimano 4-piston hydraulic disc, MT4100 lever, MT420 caliper
Brake rotor Shimano RT64, centerlock, 203mm

Weight
Weight M - 21.30 kg / 46.96 lbs (with TLR sealant, no tubes)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
