Modern MTB Design

Quality components like a 1x drivetrain, thru-axle hubs, internal cable routing (including dropper post compatibility), and integrated chainstay protection provide everything you need to build confidence and skills on the trails.

Off-Road Control

The new geometry is optimized for confident trail riding, with two wheel size options (27.5- or 29-inch) based on frame size. It’s also designed to match front suspension travel with either an 80mm or 100mm fork. All models have clearance for high-volume tires (up to 2.4 inches) for traction and grip on technical terrain.

Light and Durable

The all-new ALUXX aluminum frame features updated tube shaping and a lighter overall weight for improved performance on off-road terrain.

SPECIFICATIONS

• Sizes
  27.5": XS, S, 29": S, M, L
• Colours
  Black, Nordic Breeze
• Frame
  ALUXX-grade aluminum, disc
• Fork
  SR Suntour XCE, QR, steel steerer, XS, S: 80mm travel (27.5) S, M, L:100mm travel (29)
• Shock
  N/A
• Handlebar
  Giant Connect Trail, 31.8mm 27.5" XS: 690mm, S: 690mm 29" S: 750mm, M: 750mm, L: 750mm
• Grips
  Giant Sole-O
• Stem
  Giant Sport, 7-degree 27.5" XS: 40mm, S: 40mm 29" S: 40mm, M: 50mm, L: 50
• Seatpost
  Giant Sport, 30.9mm 27.5" XS:100x350mm, S: 100x350mm 29" S: 100x350mm, M:100x375mm, L : 100x375mm
• Saddle
  Contact Ergo
• Pedals
  MTB caged
• Shifters
  Microshift, Acolyte 1x8, SL-M6180-R
• Front Derailleur
  N/A
• Rear Derailleur
  Microshift, Acolyte 1x8, RD-M5185M with clutch
• Brakes
  TKB-172, mechanical [F]160mm, [R]160mm rotors
• Brake Levers
  RS360A, mechanical
• Cassette
  Microshift, Acolyte, CS-H083, 12-46
• Chain
  KMC 8.3
• Crankset
  ProWheel C10Y-NW 52.5mm chainline 32t (27.5") & 30t (29") 27.5" XS: 165mm, S: 165mm 29" S: 170mm, M: 170mm, L: 170mm
• Bottom Bracket
  cartridge
• Rims
  27.5": Giant GX03V 27.5", alloy, double wall, 21mm inner width 29": Giant GX03V 29", alloy, double wall, 21mm inner width
• Hubs
  alloy, sealed bearing
• Spokes
  stainless, 14g
• Tires
  Maxxis Ikon 27.5x2.4" or 29x2.4", 60tpi wire bead
• Extras
  2.4" max tire size, max chainring 32T
• Weight
  The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
