Modern MTB Design

Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models

Off-Road Control

New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.

Light and Durable

All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.

TECHNICAL SPECIFICATIONS

• Sizes
  27.5: XS, S, 29: S, M, L, XL, XXL
• Colours
  Stealth Chrome, Plasma Coral
• Frame
  ALUXX-grade aluminum, disc
• Fork
  SXC32-2 RCL, air spring, thru axle, steel steerer, 15x110 XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M:100mm travel (29) L: 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)
• Handlebar
  Giant Connect Trail, 31.8mm XS: 690mm (27.5) S: 690mm (27.5) / 750mm (29) M: 780mm (29) L: 780mm (29) XL: 780mm (29) XXL: 780mm (29)
• Grips
  Giant Sole-O
• Stem
  Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29) XXL: 90mm (29)
• Seatpost
  Contact Switch AT Core, 30.9, dropper, remote under bar, 110-140mm travel XS: 395mm (27.5) S: 395mm (27.5/29) M: 395mm (29) L: 395mm (29) XL: 395mm (29) XXL: 395mm (29)
• Saddle
  Giant ErgoContact Trail
• Pedals
  platform
• Shifters
  Shimano Deore M6200, 1x12
• Rear Derailleur
  Shimano Deore M7200, Shadow ES
• Brakes
  Shimano BR-MT200, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm
• Brake Levers
  Shimano BL-MT201
• Cassette
  Shimano Deore M6200, 10x51
• Chain
  KMC X-12
• Crankset
  ProWheel MPX, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29) XXL: 175mm (29)
• Bottom Bracket
  Cartridge
• Rims
  Giant tubeless compatible 29 or 27.5, alloy, double wall, 21mm inner width
• Hubs
  [F] Shimano, sealed bearing, 15x110 thru axle, [R] 12x142 thru-axle
• Spokes
  stainless, 14g
• Tires
  Maxxis Rekon 27.5x2.4" or Maxxis Rekon Race 29x2.4", wire bead
• Max Tire Clearance
  2.4"
• Max Chainring Size
  32T
• Weight
  The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
