Trek FX+ 2 Step-Over Fitness Electric Bike 2027

FX+ 2 is a pedal-assist fitness e-bike with a throttle backup, built for fast commutes and everyday rides. With assist up to 20mph and an optional throttle when you need it, this bike gives you the flexibility to push harder or coast home in comfort. A suspension fork and seatpost soak up bumps, and wide gravel tires keep you stable across changing surfaces. Fully equipped with lights, turn signals, rack, and Trek Central app integration.

SPECIFICATIONS

*Please note - spec applies to all sizes unless listed separately

Frameset
Frame
Alpha Gold Aluminum, internal cable routing, internal battery, rack & fender mounts, flat mount disc brake, kickstand mount, 144.5mm OLD hub motor spacing
Fork
SR Suntour GVX32-D, vzduchová pružina, zamykání, nastavení odskoku, rychloupínák 100 mm, zdvih 63 mm.

Wheels
*Rim
Size: S, M, L, XL
Alloy double wall, 36h
Size: S, M, L, XL
Alloy double wall, 32H
*Spokes
Size: S, M, L, XL
14g stainless steel, black
Size: S, M, L, XL
Sapim Strong, 13G stainless
Tire
Bontrager GR0 Comp, wire bead, 60 tpi, 650x50mm
Max tire size
650x50mm

E-system
Battery
520Wh integrovaný, odmontovatelný.
Charger
Trek Easy Mag charger, 2.7A, 54.9V output, 100V-240V AC input
Computer
LCD display
Motor
Hub drive motor, 60 Nm, 500W, 36H, black
E-bike Classification
Class 2

Drivetrain
Shifter
Shimano M315, 8 speed
Rear derailleur
Shimano ESSA U2000
Crank
Alloy, 40T steel chainring, 170mm length
Cassette
Shimano HG400, 11-45, 8 speed
Chain
KMC Z8.3
Pedal
Bontrager City pedals
Max chainring size
1x: 40T

Components
*Seatpost
Size: S, M
SR Suntour, odpružení, 50mm zdvih, 31,6 mm, délka 350 mm.
Size: L, XL
SR Suntour, odpružení, 50mm zdvih, 31,6 mm, délka 400 mm.
*Handlebar
Size: S, M
Bontrager alloy, 31.8mm, 15mm rise, 690mm width
Size: L, XL
Bontrager alloy, 31.8mm, 15mm rise, 720mm width
Grips
Bontrager XR Endurance Comp, lock-on
*Stem
Size: S, M
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: L, XL
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length
*Brake
Size: S, M, L, XL
Tektro HD-E3110, hydraulické kotoučové.
Size: S, M, L, XL
Tektro HD-E3110 hydraulic disc
Brake rotor
Tektro, 6-bolt, 180mm
Rotor size
Max brake rotor sizes: 180mm front & rear

Accessories
*Light
Size: S, M, L, XL
Sate-lite M-15, brake and turn signal
Size: S, M, L, XL
Sate-lite C19, přední světlo.
Kickstand
Adjustable length rear mount alloy kickstand
Cargo rack
MIK-compatible alloy rear rack
Fender
SKS wide, plastic

Weight
Weight
M - 25.30 kg / 55.78 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
