LIGHTER WEIGHT

The new Talon E+ EX frame is crafted with ALUXX SL aluminum using hydroforming and gravity casting techniques that helps make it 13% lighter than the previous generation. The new EnergyPak 430 battery and SyncDrive Sport 2 motor are also lighter, giving it an overall weight of just 21.7kg (size medium, without rack). The result is greater agility and confident off-road handling that feels more like a regular hardtail mountain bike.

SLEEK AND SLIM

The redesigned frameset features a slimmer down tube integrated with a new EnergyPak 430 battery system that’s lightweight and easily removable for external charging. 3D forging techniques and super-smooth welds give it a clean, modern look, and two bottle cage mounts allow you to carry more hydration or add a battery range extender for longer rides.

SUPER COMMUTER

The Talon E+ EX is loaded with features and accessories that make it ideal for trekking or commuting. The RideControl Dash 2 controller is used to power on the bike and adjust support levels while you ride. Using the RideControl App, you can custom tune the motor output to optimize range. Also new is a Find My Bike feature using integrated Apple AirTag functionality. And it comes with a rear carrier, fenders, a kickstand, and integrated lights.

Range

How far can I expect to ride on a single battery charge?

The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.

The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.

TECHNICAL SPECIFICATIONS

• Motor
  Giant SyncDrive Sport 3, 85Nm PedalPlus 6-sensor technology
• Controller
  Giant RideControl Dash 2, Smart Assist automatic mode, 5 support levels
• Display
  Giant RideControl Dash 2, full color LCD display
• Battery
  Giant EnergyPak 430Wh, Giant EnergyPak Plus 200Wh range extender compatible
• Charger
  Giant EnergyPak 4A smart charger
• Sizes
  S, M, L, XL
• Frame
  ALUXX aluminum, Overdrive 1½ - 1⅛" head tube, integrated KSA40 kickstand mount
• Fork
  SR Suntour XCM32, 100mm travel, 15x110mm thru-axle
• Handlebar
  Giant Connect TR riser 31.8x750mm [S/M], 31.8x780mm [L-XL]
• Grips
  Giant Sole-O
• Stem
  Giant Contact
• Seatpost
  Forged Aluminium, 30.9mm, 2-bolt micro adjustable
• Saddle
  Giant Ergo Trail ESG
• Pedals
  platform
• Shifters
  Shimano CUES, LinkGlide
• Rear Derailleur
  Shimano CUES, LinkGlide, 10-speed, Shadow+
• Brakes
  Shimano MT-200, hydraulic disc, 180mm [F/R] rotors
• Brake Levers
  Shimano MT-200
• Cassette
  Shimano CUES, LinkGlide, 10-speed, 11x48
• Chain
  Shimano LinkGlide
• Crankset
  Forged aluminium, [XS/S] 165mm, [M/L] 170mm, Direct-mount steel, 36t
• Rims
  Giant GX03V, alloy
• Hubs
  Shimano TC500, Boost, Center-Lock, 15x110mm [F] 12x148mm [R]
• Spokes
  Stainless steel
• Tires
  Maxxis Rekon, 29x2.4", wire bead, EXO, 60TPI
• Extras
  KSA40 direct mount
• Lighting
  Giant Recon E HL50 Axa BlueLine Steady E6 rear
• Lock
  Giant Rack-It MIK
• Carrier
  MIK rack, system bag & basket compatibility
• Fender/Chainguard
  Co-molded, 32-38t, adjustable
• Combined Maximum Load Limit
  150kg
• Weight
  The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
