It's right for you if...

You want a bike that maximizes the fun and is up for gnarly rides that get you off the grid or just hammering in an extra lap or two. You need the capability of an enduro bike for pointing it down the rough and rowdy, and love the feeling of full assist taking the sweat out of the climb back to the top for more.

The tech you get

An Alpha Platinum Aluminum frame with a Bosch Performance CX system (85Nm, 250W), and 800Wh Removable Integrated Battery 2.0. A 160mm RockShox ZEB Select fork with DebonAir spring, Motion Control damper and lockout, and a RockShox Deluxe Select+ RT shock. All topped off with a Shimano XT and SLX blended 12-speed drivetrain, dropper post, Bontrager Line Comp 30 Tubeless Ready wheels, and 4-piston Shimano hydraulic disc brakes.

The final word

Rail + 8 is an enduro e-MTB dialed for big adventures. It packs in capable, adjustable geometry, a massive battery, and a powerful motor to get you wherever you want to go. An upgraded drivetrain balances price and performance for a ride that's ready for anything.

Why you'll love it

1. Rail+ delivers adventure with plenty of travel and power for getting after epic rides that take you peak to peak or chasing endless enduro laps
2. The powerful Bosch Performance CX system goes full gas up steep climbs and keeps you cool for the descents
3. You can tweak your geometry and suspension leverage rate for how you ride, and add in adjustable angle headset cups (sold separately) for even more adjustability
4. The massive 800Wh RIB 2.0 battery supports you for big miles and can be easily removed for travel or storage
5. It's compatible with the Bosch PowerMore booster battery for going even further on epic adventures

SPECIFICATIONS

*Please note - spec applies to all sizes unless listed separately

Frameset
Frame    Alpha Platinum Aluminum, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armor, Boost148, 12mm thru axle, 160mm travel
Fork    RockShox ZEB Select, DebonAir spring, Charger RC damper, tapered steerer, 44mm offset, Boost110, Maxle Stealth, 160mm travel
Shock    RockShox Super Deluxe Select+ RT, 205mm x 65mm
Max compatible fork travel    180mm

Wheels
*Wheel front    Size: S
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 27.5''
Size: M, L, XL
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29''
Wheel rear    Bontrager Line Comp 30, High Strength 6000 Series Aluminum rim, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 27.5''
Skewer rear    Bontrager Switch thru axle, removable lever
*Tire    Size: S, M, L, XL
Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50"
Size: M, L, XL
Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.50"
Tire part    Bontrager TLR sealant, 180 ml/6 oz
Max tire size    Frame: 27.5x2.60", Fork: See manufacturer

E-system
Battery    Bosch PowerTube 800Wh, smart system
Charger    Bosch standard 4A, 110V, smart system
Controller    Bosch System Controller BRC3100, smart system
Motor    Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)

Drivetrain
Shifter    Shimano SLX M7100, 12 speed
Rear derailleur    Shimano XT M8100, long cage
Crank arm    E*thirteen E*spec Plus, 160mm length
Cassette    Shimano Deore M6100, 10-51, 12 speed
Chain    Shimano SLX M7100, 12 speed
Pedal    VP-536 nylon platform
Max chainring size    1x: 36T

Components
Saddle    Bontrager Verse P3, steel rails
*Seatpost    Size: S
Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length
Size: M, L, XL
Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 4500mm length
Size: L, XL
Bontrager Line Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 5150mm length
Handlebar    Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width
Grips    Bontrager XR Trail Comp, nylon lock-on
Stem    Bontrager Elite, 35mm, 0 degree, 45mm length
Headset    Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible
Brake    SRAM DB 8 4-piston hydraulic disc
Brake rotor    SRAM CenterLine, 6-bolt, round edge, 200mm
Rotor size    Max brake rotor sizes - Frame: 220mm, Fork: see fork manufacturer

Weight
Weight    M - 25.08 kg / 55.3 lbs (with TLR sealant, no tubes)
Weight limit    This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
